Power Take Off

This programme supported a wide range of Power-Take Off systems that each proposed a step change in the capital cost and/or efficiency/performance over current technology.

Power Sharing Transmission based Bi-directional to Uni-directional PTO (PST-PTO)

Cofely Fabricom

This project evaluated the efficiency, flexibility and robustness of an electro-mechanical PTO system which transforms bi-directional movement into a uni-directional rotation.

Edinburgh Designs Adaptive Power Take Off (EDAPTO)

Edinburgh Designs Ltd

A design study for an advanced, hybrid electro-hydraulic power take off system that aims to drive forward a step change in the levelised cost of energy.

'WEC-Direct' - Contra-rotating generator

Energy Systems Research Unit, University of Strathclyde

This feasibility study investigated the application of a direct drive, contra‐rotating generator to different WEC architectures.

Power Electronic Controlled Magnet Gear (PECMAG)

Ecosse Subsea Systems Ltd

A feasibility study to determine if a novel electric generator with an integral magnetic gearing system, developed for a lightweight wind turbine generator, can be adapted for use as a PTO system by…

GATOR - a compliant seal free hydraulic PTO

Exceedence Ltd

The project aimed to develop and test a novel, innovative hydraulic PTO concept consisting of a flexible compliant polymer spring tube.

New Electric Automotive Power Extraction Device (NEAPED)

Marine Design International Ltd

This project investigated the feasibility of technology transfer from the automotive industry to the wave energy sector. NEAPED used the latest mass produced electric vehicle technology as the basis…

Advanced Hydraulic-electric Power Take Off (AHPTO)

Nova Innovation Ltd

This PTO design aimed to utilise a novel combination of proven hydraulic and power electronic systems to increase the power capture, reliability, controllability and grid compatibility of WECs.

Wave Energy Transmission Module

Romax Technology Ltd

This project developed a PTO module comprising a gearbox and generator capable of converting the reciprocal motion of a wave energy converter into grid-compliant electricity at a low cost of energy.

Direct contact dielectric elastomer PTO for submerged wave energy converters

Scuola Superiore di Studi Universitari e di Perfezionamento Sant' Anna

The project aimed to develop a breakthrough technology for direct conversion of oscillating mechanical energy of ocean waves into electricity through the employment of dielectric elastomer generators.

Survivable and Efficient OLeo-hydraulic assisted power Take Off (SEÒLTA)

Fundación TECNALIA Research & Innovation

This project characterised and assessed the feasibility of a novel hybrid PTO configuration that is inspired by those used in the automotive sector which have significantly reduced fuel consumption.

Hybrid Digital Displacement® hydraulic PTO for wave energy

Artemis Intelligent Power Ltd

The project integrated Artemis Digital Displacement Pump-Motor (DDPM) technology into a state of the art PTO system to produce a ‘hybrid’ with a combined capability greater than the sum of its parts.

Blue Power Take Off

Blue Power Energy Ltd

The Blue Power PTO, based on ballscrew technology, aimed to achieve early and reliable deployment suitable for a range of WEC designs by utilising existing hardware components in a novel application.

Concept Optimisation of a Variable Damping Linear Power Take Off

Oscilla Power Ltd

This project optimises and demonstrates its variable damping linear drivetrain concept, which combines a linear hydraulic “gearbox” with either a conventional or an advanced linear generator.

WaveDrive

Trident Energy Ltd

The WaveDrive project progressed the design and development of a low cost, highly reliable and highly controllable linear generator (LG) power take off (PTO) technology for wave energy converters.

EMERGE (Electro-MEchanical Reciprocating GEnerator)

Umbra Cuscinetti S.p.A.

The ENERGE project demonstrated the advantages of using a reciprocating linear drive featuring a high efficiency, recirculating ballscrew technology to convert energy from ocean waves to electricity.

C-GEN Direct Drive PTO

University of Edinburgh

The C-GEN generator is a novel direct drive linear generator which is easy to manufacture and assemble, as well as being highly efficient over a wide range of loads.

HiDrive - A direct drive PTO for resonant Wave Energy Converters

CorPower Ocean AB

This project aimed to deliver a highly reliable PTO solution using innovative control technology offering a step-change improvement in performance and cost to the wave energy sector.

PTO Guidance - All Stages

Wave Energy Scotland Ltd

Guidance documents for all Stages of the PTO programme, entry to which took place in 2015.
